Mfr Part Number: PS-SPR-0500NHFAWU-1

Features:

One Button to Your Desired Color

10 LED Light Bulbs

Ultra Quiet 120mm Fan

High Amperage Single +12V Rail

Multiple Connectors

80 PLUS Certified and Kaby Lake Ready

RGB Lighting Provides Best Aesthetics for All Chassis

Maximum Power: 500 W

Input:

Voltage: 100 VAC ~ 240 VAC

Current: 8 A max

Frequency Range: 50 ~ 60 Hz

Form Factor: Intel ATX 12V 2.3

Efficiency: 82-86% efficiency @ 20-100% load

Hold up Time: 16msec (minimum) within 60% load

Power Good Signal: 100 ~ 500 ms

Power Factor Correction: Active PFC

Fan: 120mm Fan (1800 R.P.M. ± 10%)

MTBF: 100,000 hours

Output: +3.3V @ 20A; +5V @ 15A; +12V @ 35A; -12V @ 0.5A; +5VSB @ 2.5A

Connectors: 1x 20+4-pin Main Power Connector, 1x 4+4-pin ATX 12V Connector, 2x 6+2-pin PCI-Express Connectors, 6x 4-pin SATA Connectors, 3x 4-pin Peripheral Connectors, 1x Floppy Connector

Safety Approval: CE/CB/TUV/ UL/ FCC/ EAC

Protection: OVP, OPP, SCP

Color: Black

Dimension (WxDxH): 150.0 x 140.0 x 86.0 mm
