UNLOCKED POTENTIAL

Achieve peak performance on your CPU with substantial cooling capacity for high frequency overclocking. The AK620 features a maximum heat dissipation power of 260W and improved airflow to lower temperatures during demanding system applications.

MULTI-PLATFORM SIMPLICITY

The all-metal mounting bracket kit provides a sturdy and easy installation process for both Intel and AMD platforms with additional tools included.

Application For

Intel

LGA2066/2011-v3/2011/1700/1200/1151/1150/1155

AMD

AM4/AM3+/AM3/AM2+/AM2/FM2+/FM2/FM1

Technical Spec

| Product Dimensions

| 129×138×160 mm

| Heatsink Dimensions

| 127×110×157 mm

| Net Weight

| 1456 g

| Heatpipe

| Ø6 mm×6 pcs

| Fan Dimensions

| 120×120×25 mm

| Fan Speed

| 500~1850 RPM±10%

| Fan Airflow

| 68.99 CFM

| Fan Air Pressure

| 2.19 mmAq

| Fan Noise

| ≤28 dB(A)

| Fan Connector

| 4-pin PWM

| Bearing Type

| Fluid Dynamic Bearing

| Fan Rated Voltage

| 12 VDC

| Fan Rated Current

| 0.12 A

| Fan Power Consumption

| 1.44 W

| EAN

| 6933412727316

| P/N

| R-AK620-BKNNMT-G

Product Dimension

| Product Specifications

| Advance Feature

| Four direct contact heat pipes for continuous contact between CPU and coolerUpgradable to dual fans with quick snap fan bracket; clicks and noisy vibrationsQuiet Spin-Exclusive technology stabilizes the driver that spins the blades; reducing Wide-range PWM fan with unique blade design and red LEDsVersatile all-in-one mounting solution for Intel and AMD sockets

| Fan Specifications

| Fan Speed

| 600 – 1600 RPM

| Fan Bearing

| Rifle Bearing

| Noise Level

| 9 – 31 dBA

| Current

| 0.19A

| Fan Voltage

| 12V

| Application

| Intel: LGA 2011-v3/ 2011/ 1366/ 1156/ 1155/ 1151/ 1150/ 775AMD: Socket FM2+/ FM2/ FM1/ AM3+/ AM3/ AM2+/ AM2

| Fan Feature

| Connector: 4 PinLife Expectancy: 228 hrsAir Pressure: 1.7 mm H2O

| Heatsink

| Material

| 4 Heat Pipes / Direct Contact / Aluminum Fins

| Heatpipe

| 6 mm
